               2013 Reevaluation of the Beaumont Basin Safe Yield                                                                                 3-Apr-15

               During storm events, a portion of the precipitation falling on the land surface in the Study Area
               runs off and is routed into the stream channels.  All of the streams in the Study Area are unlined
               except  for  an  approximate  2,600  ft  section  of  Noble  Creek  immediately  downstream  of  its
               confluence with Little San Gorgonio Creek.  A portion of the surface water runoff that occurs in
               unlined  stream  channels  infiltrates  into  the  subsurface  and  becomes  groundwater  recharge.
               Although there are no stream gages in the Study Area, observations of surface water flow in the
               stream  channels  during  minor  precipitation  events  suggests  that  surface  water  flow  in  Noble
               Creek generally infiltrates into the subsurface before reaching San Timoteo Creek (see Figure 10
               for stream channel locations).  Surface water flow in Noble Creek reaches San Timoteo Creek
               during flash flood events and prolonged periods of precipitation.  Surface water flow in Marshall
               Creek does not typically reach San Timoteo Creek except during flash flood events or during
               prolonged periods of precipitation (Personal communication with BCVWD staff, 2013).

               Deep infiltration and groundwater recharge from runoff in stream channels was estimated based
               on the USGS Infil v3 model.  The model provided the magnitude and location of recharge within
               the stream channels.  The resulting recharge was incorporated into the groundwater flow model
               using the recharge package and adjusted during calibration.  It is noted that deep infiltration in
               San Timoteo Creek was not estimated using the Infil v3 model but was instead simulated based
               on  stream  discharges  from  the  City  of  Beaumont’s  WWTP  and  assumptions  for  streambed
               conductance using the MODFLOW stream package (see Section 5.8.2).



               4.1.3  Subsurface Inflow from Outside the Study Area

               Subsurface inflow to the aquifers in the Study Area occurs primarily from the Yucaipa area with
               a  lesser  amount  from  the  South  Beaumont  area.    Subsurface  inflow  is  addressed  via  a  time-
               varying specified head boundary condition in the groundwater flow model and estimated as a
               result of the calibration process.  The groundwater flow model boundary conditions are shown
               on Figure 29.



               4.1.4  Subsurface Inflow from the Mountain Block
               Mountain block recharge represents the water that enters the hydrologic groundwater basin along
               the  bedrock  alluvial  interface  plus  subsurface  underflow  where  Little  San  Gorgonio  Creek,
               Noble Creek, and Smith Creek enter the basin (see Figure 29).  Groundwater recharge along the
               bedrock alluvial interface was simulated in the groundwater flow model using a General Head
               Boundary condition with initial estimates based on Rewis et al. (2006) which were then adjusted
               during calibration.  Subsurface underflow in the alluvial area where Little San Gorgonio Creek
               and Noble Creek enter the groundwater basin was estimated based on a flownet analysis of this




                                                             23
