                                                                           Figure 28




 Comparison of Inflows and Outflows in the Beaumont Model



 40,000                                      Storage In

 Groundwater Inflows (acre-ft)   30,000      Imported Water
                                             Return Flow





                                             Deep Infiltration of Precipitation
 20,000
                                             and Runoff in Stream Channels
                                             Subsurface Inflow from the
                                             Mountain Block
                                             Streambed Infiltration in San
 10,000
                                             Timoteo Creek
                                             Subsurface Inflow along the County
                                             Boundary
 0                                           Storage Out



                                             Subsurface Outflow
 Groundwater Outflows (acre-ft)   (20,000)   Evapotranspiration
 (10,000)
                                             Groundwater Pumping






                                             Groundwater Discharge to San
                                             Timoteo Creek
 (30,000)




 (40,000)
